Specs
| Engine | GX120 |
| Displacement | 118cc |
| Bore and stroke | 2.4" x 1.7" |
| Compression Ratio | 8.5:1 |
| Oil Alert | N/A |
| Pump type | High Pressure, Centrifugal, Self-priming |
| Volute | Rigid Mounted Cast Iron |
| Impeller | Cast Iron |
| Mechanical Seal (Pump case / impeller) | Carbon/Ceramic |
| Priming time | 80 sec. at 16.4 ft. |
| Drive system | Direct |
| Discharge capacity | 98 gals./min. |
| Suction port diameter | 1.5" NPT |
| Discharge port diameter | 1.5" NPT |
| Total head lift | 131 ft. |
| Suction head lift | 26 ft. |
| Maximum pressure | 57 psi |
| Solids handling | N/A |
| Dimensions (LxWxH) | 16.3" x 14.2" x 16.3" |
| Dry weight | 49 lbs. |
| Fuel Capacity | 0.53 gal |
| Run Time @ Max Discharge | 1.5 hr |
| Strainer Part # | 78325-YB7-020 |
| Residential Warranty | 3 years |
| Commercial Warranty | 3 years |
